DIP Machine

I.C.T-S7000 | Eyelet Pin Insert Machine

High-speed insertion: Achieves 12,000 pins per hour.
Dual bowl feeder: Ensures continuous pin supply.
PCB size range: Supports 50×50 to 400x400mm boards.
Insertion rate: 12,000 pieces per hour for bulk pins.
I.C.T support: Expert engineers provide SMT solutions.

Description

I.C.T-S7000 Eyelet Pin Insert Machine

The I.C.T-S7000 Eyelet Pin Insert Machine is designed for high-speed, precise insertion in SMT and THT production lines. With a rate of 12,000 pins per hour, this machine ensures efficient operations for bulk eyelet pins. Its dual bowl feeder and advanced bent foot detection reduce downtime and enhance accuracy. The Eyelet Pin Insert Machine features a double head for stable performance and a vibrating feeder for smooth pin delivery. Suitable for PCBs sized 50×50 to 400x400mm, it supports automated processes with X-Y servo motors, making it ideal for manufacturers seeking reliable, high-quality insertion solutions. Contact I.C.T for tailored support.

Top Features of Eyelet Pin Insert Machine

High-Speed Pin Insertion

1-1 I.C.T-Insertion Machine-JM20

The Eyelet Pin Insert Machine delivers 12,000 pins per hour, ideal for high-volume production. Its double head operation ensures consistent speed and stability, reducing cycle times. The dual bowl feeder minimizes interruptions by maintaining a steady pin supply. This feature suits manufacturers aiming to increase throughput without sacrificing quality, making the Eyelet Pin Insert Machine a reliable choice for THT lines.

Precision Pin Placement

1-2 I.C.T-Insertion Machine-JM20

Accuracy is key with the Eyelet Pin Insert Machine. Advanced bent foot detection prevents errors, while the conical nozzle and head cylinder drive ensure precise pin insertion. The machine handles PCBs from 0.79 to 2.36mm thick, supporting various applications. This precision reduces rework and enhances product quality, making it essential for industries requiring reliable eyelet pin insertion.

Automated PCB Handling

1-3 I.C.T-Insertion Machine-JM20

The Eyelet Pin Insert Machine features an X-Y servo motor system for efficient PCB transport. The loader conveyor moves boards to the work table, and the unloader conveyor handles completed PCBs. This automation streamlines production, reducing manual labor and errors. With a PCB size range of 50×50 to 400x400mm, it’s versatile for diverse manufacturing needs.

Seamless SMT Integration

1-4 I.C.T-Insertion Machine-JM20

Designed for SMT and THT lines, the Eyelet Pin Insert Machine works with wave soldering and other I.C.T equipment. Our engineers provide expert support to ensure smooth integration and operation. This compatibility enhances overall line efficiency, making the machine a valuable addition for manufacturers seeking cohesive production solutions.

Specifications

Insertion Rate: 12,000 PCS/H
PCB Size: 50×50 to 400x400mm
PCB Thickness: 0.79 to 2.36mm
Insert Head: 2 pieces
Insert Direction: 0-360°
Component Height: 0-18mm
Component Interval: 3mm
Machine Size: 1700x1500x1800mm
Weight: 1800kg

Case Study Video Introduction-Radial Lead Component Insertion Machine

Watch our case study video showcasing the I.C.T-S7000 Eyelet Pin Insert Machine in action. It highlights the machine’s high-speed insertion, precision, and seamless integration into a THT production line. See how the dual bowl feeder and X-Y servo system optimize efficiency for a client’s PCB assembly. This video demonstrates real-world performance, proving why the Eyelet Pin Insert Machine is trusted for quality manufacturing. Contact I.C.T for more insights.

More DIP Assembly Line Machines

I.C.T Selective Wave Soldering Machine DIP Line5

Equipment	Description
Loader	Loads PCB into the production line automatically.
Auto Insertion Machine	Insert DIP component on PCB.
Conveyor	Moves PCB smoothly between machines.
Wave Soldering Machine	Melts solder to bond components securely.
Selective Solder Machine	Melts solder to bond components securely.
AOI Machine	Inspects PCB for defects automatically.
Unloader	Removes finished PCB from the line.

PCB Loading

Insert DIP Component

Insert Odd Component

Wave solder

Selective Wave Solder

DIP AOI

Customer Training Success-Preforming Machine Tht Radial Lead Cut

I.C.T engineers recently completed equipment setup and training at a client’s factory. After installing the Eyelet Pin Insert Machine, our team provided hands-on guidance to ensure smooth operation. A group photo with the client’s staff reflects their satisfaction with our service. This successful collaboration highlights I.C.T’s commitment to delivering reliable equipment and expert support for optimal production outcomes.

Positive Customer Feedback-Client Praise for I.C.T

Clients consistently praise I.C.T’s Eyelet Pin Insert Machine and services. They highlight the equipment’s high quality, reliable performance, and durability in SMT and THT lines. Customers also appreciate our engineers’ fast responses to pre-sales questions and quick resolution of after-sales issues. This feedback underscores I.C.T’s dedication to providing top-notch equipment and support, ensuring client satisfaction.

Industry Certifications-Trusted Quality Standards

The I.C.T-S7000 Eyelet Pin Insert Machine holds CE certification, meeting strict European safety standards. Our company is ISO 9001 certified, and the machine includes patented technology, ensuring reliability and innovation. These certifications reflect I.C.T’s commitment to delivering high-quality, compliant equipment for global manufacturing needs.

About I.C.T Company and Teams

I.C.T is a leading provider of SMT and THT equipment, including the Eyelet Pin Insert Machine. With years of experience, we offer innovative solutions to enhance manufacturing efficiency. Our expert engineers provide tailored support, from setup to training, ensuring seamless integration. Certified with CE and ISO 9001, I.C.T delivers reliable, high-quality equipment to clients worldwide, fostering long-term partnerships.

Frequently Asked Questions

What PCBs can the Eyelet Pin Insert Machine handle?

It supports PCBs ranging from 50×50 mm to 400×400 mm, with thicknesses from 0.79 mm to 2.36 mm. This versatility allows operators to process single- and double-sided boards, including multi-layer designs, for automotive, industrial electronics, and consumer devices. Adjustable guides and modular fixtures ensure consistent placement across different board sizes, making it suitable for both low-volume prototyping and high-volume production in home, office, or multi-device SMT/THT lines.
How does the Eyelet Pin Insert Machine ensure accuracy?

The machine maintains precise pin placement through bent foot detection and a conical nozzle design that aligns each pin perfectly before insertion. Closed-loop sensors and servo-driven motors monitor placement in real time, compensating for PCB warping or uneven surfaces. This ensures reliable positioning for dense layouts, complex boards, or high-mix production, minimizing rework and improving yield for through-hole eyelet pins in automotive, industrial, and consumer electronics applications.
Can the Eyelet Pin Insert Machine integrate with other equipment?

Yes. The machine is designed to seamlessly connect with I.C.T’s wave soldering systems, SMT lines, and automated handling conveyors. Its SMEMA-compatible interfaces allow for inline production setups, enabling continuous workflows for multi-device boards. Integration supports traceability, MES data collection, and coordinated operation with upstream and downstream equipment, ensuring consistent throughput and quality control across home, office, and industrial SMT/THT lines.
What support does I.C.T offer for the Eyelet Pin Insert Machine?

I.C.T provides comprehensive support, including on-site setup, operator training, and rapid after-sales service. Engineers assist with installation, programming, and process optimization to ensure the machine operates efficiently from day one. Remote guidance and spare parts delivery are available worldwide, helping multi-device SMT and THT production lines maintain uptime, meet quality standards, and quickly adapt to new board designs or pin specifications in automotive, consumer, and industrial applications.
What is the insertion speed of the Eyelet Pin Insert Machine?

The machine can insert up to 12,000 eyelet pins per hour, supporting high-volume production without sacrificing accuracy. High-speed servo motors and synchronized feeders reduce cycle time while maintaining precise placement, even on dense PCB layouts. This capacity is ideal for automotive, industrial, and consumer electronics production lines requiring fast, reliable throughput. Operators can adjust feeder and insertion settings for multi-device boards or batch production to optimize efficiency.

Additional information

Model	I.C.T-Z4020 Axial Insertion Machine
Type	Online
Theoretical Speed	24000CPH
Feeder Position	20 STD (30, 40, 50, 100 Option)
Plug-in Angle	4 Direction 0°, 90°, 180°, 270°, 360°
Lead Spacing	5-20mm
PCB Size	5050-350300mm(Option: 400*300mm)
Power Supply	AC220V, Single Phase, 50/60HZ, 1.5Kw
Dimension	L1900W1500H1700mm
Weight	Approx 1200kg
