I.C.T-D400 | PCB Dispensing Machine
Gantry three-axis design for high stability and accuracy
Advanced vision system with mark point alignment
Jet dispensing valve enables non-contact high-speed dispensing
Adjustable conveyor fits PCBs from 50mm to 600mm
Positioning accuracy up to ±0.01mm
Supports multiple glue types and syringe sizes
Full MES connectivity and CE-compliant design
I.C.T offers global technical support and after-sales service
Description
High-Speed PCB Dispensing Machine Solution
This high-end PCB Dispensing Machine is built for speed, precision, and consistency. Designed for modern electronics manufacturing, it handles a wide range of glue types and PCB sizes with ease. The machine uses a non-contact jet dispensing method that ensures fast, clean, and accurate glue application without touching the board surface. It is perfect for applications like SMT red glue dispensing, lens assembly, chip sealing, and medical products. The built-in vision system allows accurate alignment using mark points, and the advanced motion control guarantees repeatable performance. The machine supports MES connection, CE certification, and comes with full support from I.C.T’s global service network. Whether you’re assembling LED modules, power supplies, or precision electronics, this PCB Dispensing Machine will help you boost productivity, reduce waste, and improve product quality.
Key Features of the Dispensing System
Reliable System for High-Precision Dispensing
This PCB Dispensing Machine is engineered for industrial-scale operations that demand precision and efficiency. Using servo motors and high-quality components from Japan and Europe, the machine ensures stable, repeatable, and accurate dispensing results.
It adapts to various production needs with flexible PCB handling, high-speed jet valves, and temperature-controlled glue dispensing. With an easy-to-use PC-based system and visual interface, users can program and adjust parameters quickly. Whether you’re working in electronics, automotive, or medical fields, this system delivers consistent results every time.
Precision Jet Dispensing Technology
This dispensing system uses a servo-driven screw mechanism and a non-contact jet valve for precise glue control. It supports a wide variety of fluid types, with pre-heating to optimize viscosity. The coaxial vision light ensures accurate mark point recognition, while edge compensation ensures consistency across boards. This feature is essential for small or complex assemblies where even a tiny error can cause failure.
Stable and Adjustable Conveyor System
Designed for maximum PCB stability, the anti-static belt conveyor uses independent motors for precise movement. Width adjustment is fully synchronized with a screw-based guide rail system, keeping everything parallel and consistent. A special board stop device keeps the PCB in place, preventing misalignment during operation. The system supports both left-to-right and right-to-left transport options.
Self-Cleaning with Smart Calibration
Glue valve blockages are minimized thanks to the built-in cleaning module. It also includes one-key auto-calibration for the coordinate system, saving time and effort during setup. Accurate temperature control improves glue flow and bonding quality, leading to better product reliability and longer service life.
Specification of Visual Glue Dispenser
- Max PCB size Double rail max: 50*50mm~350*350mm
- Max PCB weight: 5kg
- PCB height: 23mm
- Max component height: Max 30mm above board, max 45mm below board
- Position accuracy: ±0.025mm CPK＞1.33 3sigma
- Repeated accuracy: ±0.01mm CPK＞1.33 3Sigma
- Running speed: 800mm/s
- Driving method: Servo motor + high precision screw
- Axis: Three axis X/Y/Z
- Camera pixels: 1.3 million pixels
- Field of vision: 6*9mm
- Power: AC220V±10%, 50/60HZ
- Dimension: 850*1435*1480mm
- Weight: 900kg
Watch Our Jet Dispensing System in Action
See the PCB Dispensing Machine in real factory conditions.
This video shows our D600 dispensing machine in action with key highlights including the nozzle’s constant temperature system, non-contact jet dispensing, and precise glue volume control. You’ll also see imported motion components at work, ensuring stable and smooth operation. From high-speed dispensing to easy-to-use features, this video offers a complete look at what makes I.C.T’s system stand out in global electronics manufacturing.
More Coating Line Machines
| Equipment | Description |
|---|---|
| Loader | Efficiently loads PCBs into the production line |
| SMT Glue Dispensing Machine | IPrecisely applies adhesive for secure PCB assembly |
| Conveyor | Smoothly transports PCBs through the coating process |
| PCB Vertical Curing Oven | Quickly cures coatings for vertical PCB stability |
| IR Curing Oven | Uses infrared heat for fast, even coating curing |
Rapidly hardens coatings with UV light exposure | |
| Unloader | Safely unloads finished PCBs from the line |
Installation and Customer Training On-Site
Our engineers provide on-site installation and training to ensure smooth operation. After training, customers often take group photos with our team, showing their satisfaction and trust in I.C.T’s expertise.
Customer Feedback and Recognition
Many customers praise our SMT equipment and support team. From fast responses before purchase to quick solutions after delivery, our service earns high ratings around the world. Quality, speed, and support—that’s the I.C.T promise.
Certified Quality and Global Standards
Each machine comes with CE certification, ISO9001 compliance, and key patent certificates. These certifications ensure our PCB Dispensing Machines meet the strict safety and performance standards required in global markets.
About I.C.T Company
I.C.T is a professional manufacturer of SMT and dispensing solutions with over 25 years of experience. We offer full production lines, from printers and pick-and-place machines to industrial dispensing equipment for electronics. With service teams in Asia, Europe, and the Americas, we are always ready to support your business needs.
Frequently Asked Questions
It supports a wide range of adhesives, including red glue, UV glue, silicone, and conductive glue. This versatility allows the machine to handle diverse electronics assembly tasks, from home or office prototyping to multi-device industrial SMT production. Operators can adjust dispensing parameters for different viscosities and curing methods, ensuring consistent coverage and reducing defects across complex PCB layouts.
Additional information
| Product Weight | Max.4.5kg |
|---|---|
| Product Thickness | Max.6mm |
| Maximum Speed | 2000mm/s |
| Vision Methodology | CCD |
| Cleaning System | Auto |
| Injection Valve Speed | 200 points/s |
| Dispensing Accuracy | ±0.02mm |
| Repeated Accuracy | ±0.01mm |
