I.C.T-GP700 | Automatic Epoxy Dispensing Glue Potting Machine
- Reliable Components: Panasonic PLC and motor for durability.
- SMT PCB Metal Coating Machines: Enhances coating precision in SMT lines.
- Coating Spraying Gluing Machine for PCB LED: Ideal for LED and PCB applications.
- PCB Coating Spraying Gluing Machine: Consistent glue application for PCBs.
- I.C.T Support: Expert SMT engineers for setup and training.
Description
I.C.T-GP700 Glue Potting Machine Overview
The I.C.T-GP700 Glue Potting Machine simplifies your potting process with advanced automation, precision, and efficiency. Designed for industries like electronics and SMT assembly, this machine ensures consistent glue application, reducing labor and improving quality. With features like vacuumizing, automatic curing, and a user-friendly PLC touch screen, the Glue Potting Machine meets diverse manufacturing needs. Its high-precision screw rail and robust components guarantee reliable performance. Whether for silicone, epoxy, or PU, this machine handles various glue types with ease. Contact I.C.T for a solution tailored to your production line.
Trust I.C.T for quality and innovation in every Visual Glue Dispenser, enhancing your production line’s efficiency.
Glue Potting Machine Overview
Precision Glue Application
The Glue Potting Machine uses a high-precision screw rail and driver for exact glue placement. This minimizes errors and ensures uniform application across components, ideal for delicate SMT PCB metal coating machines. With a 3-axis system, it handles complex patterns, supporting glue viscosities up to 3500 cps. The result is reliable, high-quality potting that enhances product durability and performance, meeting the demands of modern electronics manufacturing.
Advanced Glue Monitoring
The Glue Potting Machine features an intelligent monitoring system for A and B glue levels. Sensors trigger alerts when supplies are low, preventing production interruptions. This is critical for coating spraying gluing machines for PCB LED, ensuring consistent curing. The system also monitors B glue to avoid drying issues, maintaining glue quality. This feature saves time and reduces waste, making it a cost-effective solution for manufacturers.
Efficient Cleaning Process
The automatic cleaning function of the Glue Potting Machine simplifies maintenance. With a single key press, the system cleans the glue path, reducing downtime. This is especially useful for PCB coating spraying gluing machines, where clean glue paths prevent impurities. The multi-stage filtration system further ensures glue purity, enhancing potting reliability. This feature keeps your production line running smoothly with minimal effort.
High Potting Efficiency
The Glue Potting Machine replaces 5-6 workers with its automated potting and curing. Integrated glue mixing and a high-precision gear pump ensure consistent glue output, perfect for Automatic Solder Paste Dispenser applications. With a 30L A-tank and 10L B-tank, it supports high-volume production. This efficiency reduces labor costs and boosts output, making it a smart choice for electronics manufacturing.
Specification of Visual Glue Dispenser
- Max PCB size Double rail max: 50*50mm~350*350mm
- Max PCB weight: 5kg
- PCB height: 23mm
- Max component height: Max 30mm above board, max 45mm below board
- Position accuracy: ±0.025mm CPK＞1.33 3sigma
- Repeated accuracy: ±0.01mm CPK＞1.33 3Sigma
- Running speed: 800mm/s
- Driving method: Servo motor + high precision screw
- Axis: Three axis X/Y/Z
- Camera pixels: 1.3 million pixels
- Field of vision: 6*9mm
Case Study Video Introduction
Watch our case study video showcasing the I.C.T-GP700 Glue Potting Machine in a real production environment. The video highlights its seamless integration into SMT lines, precise glue application, and automated curing process. See how it enhances efficiency for SMT PCB metal coating machines and PCB coating spraying gluing machines. Our engineers demonstrate setup and operation, proving its ease of use and reliability for high-quality potting results.
More Coating Line Machines
| Equipment | Description |
|---|---|
| Loader | Efficiently loads PCBs into the production line |
| SMT Glue Dispensing Machine | IPrecisely applies adhesive for secure PCB assembly |
| Conveyor | Smoothly transports PCBs through the coating process |
| PCB Vertical Curing Oven | Quickly cures coatings for vertical PCB stability |
| IR Curing Oven | Uses infrared heat for fast, even coating curing |
Rapidly hardens coatings with UV light exposure | |
| Unloader | Safely unloads finished PCBs from the line |
Successful Client Training
At a client’s factory, our I.C.T engineers provided hands-on training for the Glue Potting Machine. The session covered setup, operation, and maintenance, ensuring smooth integration. A group photo with satisfied clients reflects their confidence in our equipment and support. This training, paired with the machine’s automation, streamlines production for coating spraying gluing machines for PCB LED, delivering consistent results.
Customer Satisfaction Feedback
Our customers consistently commend the I.C.T-GP700 Glue Potting Machine for its durability and performance in SMT applications. They highlight the machine’s quality in PCB coating spraying gluing machines and Automatic Solder Paste Dispenser tasks. Clients also value our responsive pre-sales support and fast after-sales service, resolving issues quickly. This feedback underscores I.C.T’s commitment to reliable equipment and excellent customer care.
Certified Quality Assurance
The I.C.T-GP700 Glue Potting Machine holds CE certification, ensuring compliance with European safety standards. It also meets ISO9001 requirements and includes patents for its innovative design. These certifications guarantee reliability for SMT PCB metal coating machines and other applications, giving customers confidence in our equipment’s quality and safety.
About I.C.T Company and Teams
I.C.T is a leading provider of SMT equipment, specializing in solutions like the Glue Potting Machine. With years of experience, we deliver reliable, high-quality machines for electronics manufacturing. Our expert engineers offer comprehensive support, from setup to training, ensuring seamless integration. Trusted globally, I.C.T combines Chinese manufacturing efficiency with European quality standards, making us a preferred partner for SMT PCB metal coating machines and more.
Frequently Asked Questions
It handles silicone, epoxy, PU, and other adhesives with viscosities up to 3500 cps. The system’s precision pump and nozzle control ensure even coverage for small and large components alike, making it suitable for multi-device PCB assemblies in home labs, office prototyping, or industrial SMT lines. Operators can adjust dispensing speed and volume to match different material properties for consistent potting results.
Additional information
| Model | GP700 |
|---|---|
| Nozzle Number | 1(Multiple head is option) |
| Axis Number | 3-Axis X,Y,Z |
| Table Size | <500*500mm |
| Cleaning | Auto |
| Glue A mix | Auto |
| Glue monitoring | Sensor |
| Vacuum extraction | option |
