I.C.T-410 | QR Code PCB SMT Barcode Inkjet Printer
- Printing Speed: 1.5 seconds per code.
- PCB Size: 50×50 mm to 510×460 mm.
- Coding Accuracy: 99.99%.
- Code Types: QR Code, DataMatrix, Code 128, Code 39, up to 60 digits.
- Special Features: Vibrating mirror, OCR recognition, MES integration, automatic cleaning.
- Positioning System: CCD + MARK, 3/4-point positioning.
- Power Supply: AC220V, 50/60Hz, 2.5 kW.
Description
SMT Barcode Inkjet Printer
The SMT Barcode Inkjet Printer provides fast, non-contact printing for PCB traceability. It marks barcodes, QR codes, and text with high precision, enhancing quality control. The system supports automatic code generation and data saving, ensuring reliable production tracking. I.C.T’s expert setup and training make integration easy. This SMT Barcode Inkjet Printer is perfect for electronics manufacturers needing efficient, accurate labeling for high-quality PCB assembly.
Inkjet Printer Key Features
High-Speed Printing System
The SMT Barcode Inkjet Printer uses a high-speed vibrating mirror for stable, precise printing. It marks barcodes and QR codes in 1.5 seconds, boosting production efficiency. The system ensures clear, consistent results on various PCB sizes, reducing errors. This feature is ideal for manufacturers needing fast, reliable printing for high-volume electronics assembly with robust traceability.
Advanced Code Recognition
The SMT Barcode Inkjet Printer automatically reads and verifies 2D codes, saving data for traceability. It alerts users if codes are unreadable, ensuring quality control. The OCR function enhances accuracy by recognizing characters and codes. This system supports manufacturers aiming for error-free PCB labeling, streamlining production and maintaining high standards in electronics manufacturing.
Seamless MES Integration
The SMT Barcode Inkjet Printer connects with MES systems to access work order and material data automatically. This feature enables real-time tracking and coding, improving production efficiency. It reduces manual input errors and ensures accurate data management. Manufacturers benefit from streamlined workflows and enhanced traceability, making it a valuable tool for high-quality PCB assembly.
Automatic Cleaning Function
The SMT Barcode Inkjet Printer features an automatic cleaning system for the print head, ensuring consistent performance. Developed with Hitachi, this function prevents clogs and maintains print quality. It reduces maintenance time, keeping production running smoothly. This feature is perfect for manufacturers seeking reliable, low-maintenance printing solutions for PCB assembly.
Specifications of SMT Barcode Inkjet Printer
Printing Speed: 1.5 seconds per code.
PCB Size: 50×50 mm to 510×460 mm.
Coding Accuracy: 99.99%.
Code Types: QR Code, DataMatrix, Code 128, Code 39, up to 60 digits.
Special Features: Vibrating mirror, OCR recognition, MES integration, automatic cleaning.
Positioning System: CCD + MARK, 3/4-point positioning.
Power Supply: AC220V, 50/60Hz, 2.5 kW.
Weight: Approx. 800 kg.
Dimensions: 1100x900x1400 mm.
Logo Barcode Inkjet Printer: Video Showcase
Watch our video, I.C.T SMT Inkjet Printing Machine for SMT Production Line. It demonstrates the SMT Barcode Inkjet Printer’s high-speed printing and code-scanning capabilities. The video highlights its precise barcode and QR code placement, ensuring traceability. I.C.T’s expert setup and training ensure seamless operation for efficient PCB assembly.
More SMT Line Machines
| Equipment | Description |
|---|---|
| Loader | Loads PCB into the production line automatically. |
| Auto Printer | Applies solder paste with high precision. |
| Conveyor | Moves PCB smoothly between machines. |
| Pick and Place Machine | Places components accurately on PCB. |
| Reflow Oven | Melts solder to bond components securely. |
| AOI Machine | Inspects PCB for defects automatically. |
| Unloader | Removes finished PCB from the line. |
Customer Training and Support
Our engineers at I.C.T provide hands-on training at customer factories. After assembling and debugging the SMT Inkjet Printing Machine, we ensure clients understand its operation. Group photos with satisfied customers reflect their trust in our service. This commitment to support helps businesses maximize the machine’s potential and maintain smooth operations.
Barcode Inkjet Printer: Customer Feedback
Customers praise the SMT Barcode Inkjet Printer for its speed and reliability. They appreciate I.C.T’s quick pre-sale responses and fast after-sale support. Many highlight its consistent printing quality and ease of use, making it a top choice. I.C.T’s focus on quality service earns ongoing positive reviews from global electronics manufacturers.
Certified Quality Standards
The SMT Barcode Inkjet Printer holds CE and ISO9001 certifications, ensuring safety and quality. It also includes multiple patent certificates, reflecting innovative design. These credentials showcase I.C.T’s commitment to providing advanced, reliable solutions for electronics manufacturing, meeting global standards.
About I.C.T Company
I.C.T is a leading provider of SMT and DIP assembly solutions, specializing in equipment like the SMT Barcode Inkjet Printer. With decades of expertise, we offer comprehensive support, from installation to training. Based in China, I.C.T delivers European-quality standards, ensuring efficient, dependable production lines for electronics manufacturers worldwide.
Frequently Asked Questions
The SMT barcode inkjet printer can print QR codes, 1D/2D barcodes, serial numbers, and alphanumeric text directly onto PCBs. This is essential for SMT traceability systems, PCB assembly tracking, and electronics manufacturing compliance. It is widely used in industrial production lines, LED manufacturing, and multi-device SMT environments where accurate product identification and data tracking are required for quality control and supply chain management.
Additional information
| Model | I.C.T-410 |
|---|---|
| Printer Brand | Hitachi/KGK (Japan) |
| Resolution | 40um |
| Printing Speed | 1827character/s |
| Printing Precision | ±0.1mm |
| PCB Size | L500 * W500mm; Thickness 0.5mm-6mm |
| Applicable Product | QR code,PCB ink,ink,ink barcode,logo,text,2d code,3d code,etc. |
| Position System | CCD+MARK |
| Reading Code Function | Automatically read two-dimensional code and save data, automatically record and alarm |
| System Access | Can be interconnected with ERP/MES/SAP and other systems to automatically obtain |
| Conveyor Speed | 0 ~ 100000mm/min |
| Body Size | L1050 *W1020 *H1600 mm |
| Weight | 550Kg |
