Efficient Automatic Splicing Machine I.C.T-ASM08
- CCD detection ensures 95%+ splicing pass rate
- Works with 8mm paper and embossed SMT tape
- Cutting accuracy within ±0.2 mm for high consistency
- Splicing cycle completes in just 6–12 seconds
- 24V lithium battery enables 12–14 hours of operation
- Industrial PC control system ensures process stability
- Full I.C.T support with training and remote help
- MES connection enabled for factory-level integration
Description
Automatic Splicing Machine Overview
I.C.T-ASM08 Automatic Splicing Machine brings a fast, accurate way to splice component reels in SMT production without shutting down the line. With reliable tape handling and precise cutting, the system ensures smooth transitions between reels and minimizes the risk of placement errors. Designed for use in high-volume factories, the machine supports full automation and MES connectivity, making it a valuable addition to smart manufacturing setups.. It points out issues such as missing parts, wrong setups, value shifts, joined solder spots, and board faults, then shows the problem details.
With the Off-line ICT Tester, you get clear results to fix boards before they go further in production. It uses tech like EC jet for steady tests and CMOS plus relay switch cards for safe handling. The true broadband method covers a wide range of checks. The Win7 setup makes it easy to run, with a board view that shows everything clearly. Five-wire testing reaches up to four-terminal parts, and auto program debugging speeds things up. Stats reports help track how well production is going. This Off-line ICT Tester fits well in factories that need to check boards without being tied to a production line. It comes with parts from Taiwan for power, measurement, and control, plus software in English. Overall, the Off-line ICT Tester keeps your circuit boards working right by catching errors early.
Key Features of Automatic Intelligence Splicing Machine
Vision Detection Precision
The dual-CCD system detects empty components as small as 01005 and recognizes part presence, spacing, and silk screen patterns. This visual system allows for accurate detection before cutting, helping prevent splice mistakes and improving the machine’s accuracy across different reel types.
Stable Material Handling
The high-precision motor and imported slide rails maintain the SMT tape’s alignment throughout the splicing process. With fine-toothed drive wheels and auto-adjusting tracks, the transmission module ensures consistent positioning for cutting and taping, regardless of tape type.
Long-Lasting Cutting Mechanism
The cutting module includes a built-in high-hardness blade designed for smooth, clean cuts. The system identifies the cut point with CCD guidance and can handle pre-cuts when needed. The cutter’s durability ensures minimal maintenance and extended performance life.
Reliable Splicing Accuracy
A stepper motor and vacuum pump drive a patented splicing unit that offers a 98% success rate. Heating elements enhance adhesive strength, while the design prevents tape jams. Together, they ensure every splice is accurate and production can run without interruption.
Specification
| Parameter | Specification |
|---|---|
| Tape Compatibility | 8mm paper and embossed |
| Splicing Mode | Auto Cutting + Auto Splicing |
| Splicing Accuracy | ±0.2mm |
| CCD Camera Count | 1 |
| Power Supply | 24V lithium battery ×2 |
| Battery Operation Time | 12–14 hours |
| Splicing Time per Cycle | 6–12 seconds |
| Control Method | Industrial PC |
| Dimensions (mm) | 550 × 470 × 1300 |
| Weight | Approx. 65 kg |
| MES Integration | Supported |
| Barcode Scanner | Included |
Automated Taping Machine SMT Video
This video shows the Automatic Splicing Machine at work inside a real EMS production line. It demonstrates how the machine detects empty reels, cuts accurately, and applies splicing tape with automated precision. You’ll see how fast and efficient each cycle is—just under 12 seconds! The video also highlights the system’s easy operation and compact structure, ideal for lean manufacturing setups. If you want to see what real-time tape splicing looks like, this clip is worth watching.
More SMT Machines
| Equipment | Description |
|---|---|
| Loader | Loads PCB into the production line automatically. |
| Auto Printer | Applies solder paste with high precision. |
| Conveyor | Moves PCB smoothly between machines. |
| Pick and Place Machine | Places components accurately on PCB. |
| Reflow Oven | Melts solder to bond components securely. |
| AOI Machine | Inspects PCB for defects automatically. |
| Unloader | Removes finished PCB from the line. |
I.C.T Installation and Training Success
After assembling and commissioning the Automatic Splicing Machine on-site, I.C.T engineers trained the customer’s team in real operations. The photo shows both teams standing proudly together—proof of our commitment to smooth delivery, successful training, and happy customers.
Customer Feedback
Our clients often praise the high quality and stability of I.C.T’s SMT machines. From rapid pre-sale responses to reliable after-sale solutions, customers trust our team for fast answers and hands-on support—especially when every second counts on the production floor.
Certified Quality Standards
Our splicing systems are fully certified with CE, ISO9001, and protected by multiple design patents. Each machine meets international safety and performance standards, ensuring our clients receive proven and trusted technology.
I.C.T Factory & Our Team
Founded in 2012, I.C.T is a global electronics manufacturing partner, supporting over 1600 customers in 50+ countries. We offer complete SMT line solutions, including placement, inspection, testing, and splicing equipment. Our team provides hands-on support, smart automation tools, and scalable solutions to keep your factory ahead. We’re built for speed, trust, and long-term partnership.
Frequently Asked Questions
It achieves a pass rate of over 95%, ensuring secure and precise tape reel connections. This high success rate reduces downtime caused by faulty splices and prevents SMT component misfeeds during pick-and-place operations. Reliable splicing is especially important in multi-device or high-volume EMS lines, where consistent tape continuity affects production quality and efficiency. Operators can monitor splice quality via the machine’s digital interface, allowing real-time adjustment to maintain accuracy throughout extended production shifts.
Additional information
| Model | I.C.T-ASM08 |
|---|---|
| RC Measuring Instrument | N/A |
| Applicable Mounter | Full SMT brand |
| SMT Tape(mm) | 8 Paper |
| Splicing Mode | Auto Cutting |
| Splicing Tape Size | 32mm |
| Splicing Tape Number | 1 |
| Dimension(mm) | 550*470*1300 |
| Weight | Approx: 65KG |
