Automatic Wave Unloader Wave Solder Outfeed Conveyor

Rugged steel structure ensures durability and long-term stability
Adjustable conveyor height to match soldering equipment levels
High-temperature antistatic belt protects PCBs during transfer
Compact design with customizable machine length options
Variable speed motor drive for flexible production needs
Supports left-to-right and right-to-left transfer directions
Cooling fans can be added for faster post-soldering cooling
I.C.T provides installation, training, and reliable global service

Description

Wave Unloader Overview

The Wave Unloader is designed to smoothly transfer PCBs after the soldering process, ensuring stability and safety in production lines. With its rugged steel frame and high-temperature antistatic belt, it supports continuous operation under demanding conditions. The conveyor height can be flexibly adjusted, allowing it to match different wave soldering machines. Cooling fans can also be installed to accelerate board cooling after soldering. Its modular design makes it easy to integrate into various production setups, while the heavy-duty base structure prevents shifting during long runs. The Wave Unloader provides a stable and efficient solution for DIP assembly and wave soldering lines, reducing manual handling and improving overall productivity. Supported by I.C.T’s professional engineering team, it comes with global installation, training, and after-sales service for complete customer confidence.

Key Features of Automatic Wave Soldering Unloader

Safe and Steady PCB Transfer
The Wave Unloader uses a high-temperature antistatic belt to ensure PCBs are handled safely after soldering. Its sturdy frame and heavy base provide stable operation even during continuous use.

Flexible Integration Options
With adjustable conveyor height, customizable length, and support for both transfer directions, this unloader can easily fit into any wave soldering setup, enhancing line adaptability.

Enhanced Cooling Capability
Additional cooling fans can be installed to accelerate PCB cooling after soldering. This helps maintain quality while improving production throughput in high-demand environments.

Specification

Dimension: 1200 × 485 × 1400 mm
PCB Width: 50–400 mm (customizable)
Transport Height: 750 ± 20 mm to 1300 mm
Control Mode: Motor drive with variable speed
Cooling Mode: Fan (optional multiple fans)
Transfer Direction: Left-to-right or right-to-left
Power Supply: 1 PH AC 220V 50/60 Hz (option: 110V–380V)
Power Consumption: Max 20 VA
Weight: 290 kg per set

Safe and Upgraded PCB Handling

This video presents the I.C.T Acrab Series Wave Soldering Machine, showcasing high-precision lead-free soldering, automatic solder bar addition, and PCB handling with loaders and unloaders. It also highlights real customer installations, the production process in action, and client feedback. The video demonstrates how integrated equipment ensures stable soldering results and efficient workflow in PCB assembly.

More DIP Line Machines

I.C.T Selective Wave Soldering Machine DIP Line5

Equipment	Description
Loader	Loads PCB into the production line automatically.
Auto Insertion Machine	Insert DIP component on PCB.
Conveyor	Moves PCB smoothly between machines.
Wave Soldering Machine	Melts solder to bond components securely.
Selective Solder Machine	Melts solder to bond components securely.
AOI Machine	Inspects PCB for defects automatically.
Unloader	Removes finished PCB from the line.

PCB Loading

Insert DIP Component

Insert Odd Component

Wave solder

Selective Wave Solder

DIP AOI

On-Site Setup and Training Success

I.C.T engineers provide on-site assembly, debugging, and operator training. Photos taken after installation show happy customers alongside our engineers, reflecting their trust in our service.

Positive Feedback from Our Clients

Our clients often commend the Wave Unloader for its stable design and reliability. They also value I.C.T engineers for fast responses, professional support, and efficient problem-solving before and after installation.

Certified for Quality and Safety

Every Wave Unloader comes with CE certification, ISO9001 compliance, and patented designs, ensuring safety, quality, and global recognition.

I.C.T Factory & Our Team

I.C.T Intercontinental is a global provider of SMT and DIP solutions. Since 2012, we have served over 1,600 customers with equipment ranging from loaders and unloaders to complete SMT and DIP lines. With 8 global branches and a strong engineering team, we combine Chinese manufacturing with European-level quality standards. Our mission is to deliver reliable equipment and long-term service for electronic assembly worldwide.

Frequently Asked Questions

What is the main function of an Automatic Wave Unloader in a wave soldering line?

An automatic wave unloader is used to receive PCBs after wave soldering and safely transfer them out of the soldering system. It ensures smooth outfeed handling in wave soldering production lines by reducing manual contact and preventing board damage. This wave solder outfeed conveyor is widely used in DIP assembly, PCB manufacturing, and multi-device SMT-DIP hybrid environments where stable post-solder handling is required to maintain production flow and avoid bottlenecks.
How does the Wave Solder Outfeed Conveyor improve production efficiency?

The wave solder outfeed conveyor improves efficiency by automatically transporting soldered PCBs to the next process without manual handling. This reduces cycle time, minimizes operator intervention, and ensures continuous wave soldering line operation. It is especially useful in high-volume electronics manufacturing, LED assembly lines, and industrial PCB production environments where consistent output speed and uninterrupted workflow are critical for maintaining productivity.
Can the Automatic Wave Unloader handle different PCB thicknesses?

Yes, the automatic wave unloader can handle a wide range of PCB thicknesses by adjusting conveyor rail width and transport height. This flexibility allows it to support standard FR4 boards, thick industrial PCBs, and mixed production batches. It is commonly used in wave soldering lines, DIP assembly systems, and multi-device manufacturing environments where different board specifications must be processed without machine changeover.
Is the Wave Solder Outfeed Conveyor compatible with SMEMA systems?

Yes, the wave solder outfeed conveyor fully supports SMEMA communication protocols, allowing seamless integration with upstream wave soldering machines and downstream PCB handling equipment. This ensures synchronized production flow across the entire DIP line. It is ideal for automated SMT-DIP hybrid factories, office pilot production lines, and smart manufacturing environments where machine-to-machine communication is essential for stable automation.
What safety features does the Automatic Wave Unloader include?

The automatic wave unloader includes multiple safety features such as emergency stop buttons, anti-collision sensors, and controlled conveyor speed adjustment. These safety systems protect both operators and PCBs during unloading operations. It is widely used in wave soldering production lines, electronics factories, and multi-device manufacturing environments where safe PCB handling and operator protection are required for continuous industrial operation.

Additional information

Dimension(mm)	12004851400mm
PCB Width	50 – 400mm (can be customized)
Transport Height	1300 – 750±20mm
Control Mode	Motor
Cooling Mode	Fan
Power	Max 20 VA
PCB Direction	L to R or R to L
Power Supply	1 PH AC 220V 50/60Hz (Option:110V to 380V
Weight	290Kg/set
